#375, 29.5' x 10.2'

Lineage:

This design kit was derived from our several, similarly sized fire/rescue boats and built by Viking Welding.  The profile and cabin, in particular, are similar to those earlier boats, but the bottom was substantially tweaked to trim properly with the weight and CG changes that resulted from eliminating the firefighting equipment, which generally contributes quite a bit of weight aft.  Powered by twin 300 Verados, the pictured hull topped out at about 48 mph during early sea trials without any performance tweaking.  Like it's fire/rescue boat cousins, the bow features are relatively large radius bow cone.

This is a versatile hull that would lend itself to a variety of different deck arrangements.

Particulars:

Length (hull):

  Beam (hull):

Wt. as rigged:

Wt. Bare Hull:

Deadrise Angles-

  Transom:

        Sta. 4:

  Cutwater:

29' - 6"

10' - 2" (w/o rub rails)

8,437# w/ 300 hp twin OB

5,122#



  15

  24.5

  50

Scantlings:

Bottom:

Bot. Stringers:

Sides:

Side Stringers:

Decks:

Transverse Frames:

Transom:

Chine Flats:

Keelson:

.250"

Girder & .250" x 4.25"

.190"

.250" x 3"

.190"

.190"  flanged

.375"

.375"

.500" x 5"

Stock Weight (approx.)-

                    Blank Plate: 6,742# (w/ house)

                       Extrusion: 625#
