#449, 26'  x 8.7'  Blunt Bow, Pram- Pump Out & Utility

1/1
Main Views (pdf)
Study Dwgs & Lists (pdf)
Show More

Lineage:

The hull pictured was developed for Sound Marine, Holbrook, NY and sold as a pump out boat with sewage capacity of approximately 600 gallons.  Designed specifically to handle this large, variable load, the hull would also make for a good utility/construction support boat.

Particulars:

Length (hull):

  Beam (hull):

Wt. as rigged:

Wt. Bare Hull:

Deadrise Angles-

  Transom:

        Forefoot:

26'

8' - 8" (w/o rub rails)

4,632# (150 hp outboard)

3,246# (w/ console)



5

11

Scantlings:

Bottom:

Bot. Stringers:

Sides:

Side Stringers:

Decks:

Transverse Frames:

Transom:

Keelson:

.250"

.190" Girders & 3.5" x .250"

.190"

.190" Shelves

.190"

.190" flanged

.250"

4.7 x .375"

Stock Weight (approx.)-

                    Blank Plate: 3,463#

                       Extrusion: Varies
